3D CAD software & modelling

MSM Fabrications operates at the cutting edge of metal fabrication technology.

Our advanced 3D CAD software, powered by SolidWorks, enables precise modelling to bring your projects to life with unmatched accuracy. Along with BySoft's comprehensive software solutions, we design bending programs that integrate seamlessly with our production machinery. Whether it's a simple component or complex assemblies, we ensure every detail is accounted for, from design to fabrication.

Get in touch

Advanced SolidWorks Modelling: Tailored 3D designs that meet rigorous specifications

Seamless Import Capability: Directly import your 3D models via email into our fabrication systems

Comprehensive Programming Solutions: Offline programming for laser cutters, punches, and bends

Specialised Tube Laser Cutting: Precision programming for rectangular, square, and circular tubes

Precision in fabrication starts with detailed and accurate programming.

Our suite of high-end software solutions helps create precise bending programs, which ensures that every bend in your project is correct. This capability improves the quality of the final product and significantly reduces production time by eliminating manual programming errors.

Our suite of high-end software solutions helps create precise bending programs, which ensures that every bend in your project is correct. This capability improves the quality of the final product and significantly reduces production time by eliminating manual programming errors.

Our suite of high-end software solutions helps create precise bending programs, which ensures that every bend in your project is correct. This capability improves the quality of the final product and significantly reduces production time by eliminating manual programming errors.

Who we work with

Yes. We have several clients who supply us with all the bought-out items needed to provide fully assembled, wired, and tested machinery ready to despatch from our premises to site.

Our expertise is in sheet metal fabrications and CNC machining, which are our focuses. However, if your project requires plastics or other non-metallic materials, we can manage those from other suppliers on your behalf.

Yes. We have another division – Secure Line Solutions who are approved to Ministry of Justice level and are permanently dedicated to site work and installations.

Yes, we try not to subcontract work if we can avoid it, so everything stays within our control from a scheduling and quality perspective. The only operations we subcontract are electroplating and galvanising, which are specialist processes.

For standard laser cutting work, we offer a 3-day turnaround. Larger projects will be dictated by the scope of supply.

We work to ISO9001:2018 and have in-house quality personnel on staff.

We use dedicated sheet metal working software called ProgressPlus.

"Excellent goods out team, including very professional fork truck driver. Large yard but access via narrow roads."

Andrew Holdworth

Our ability to directly import customer-provided 3D models into our systems streamlines the transition from design to production.

By enabling direct integrations, we reduce turnaround times and increase efficiency. Our advanced 3D software is specifically designed for offline programming our tube laser cutting machinery, ensuring high-precision cutting across various tube shapes and sizes.
